SE Fat Quad 26'' 2021 Complete BMX - High Polish Silver

SE Fat Quad 26'' 2021 Complete BMX

Features:

  • Frame: 6061 Aluminum, Single Downtube Fat Quad Design, Internally-machined Integrated Head Tube, Looptail Rear End, Retro Dropouts, 100mm Euro Bottom Bracket, 170mm Spaced Dropouts, Disc Brake Tabs
  • Fork: Landing Gear, Full Cr-Mo, Disc Tabs, 450mm Axle to Crown, 38mm Offset, 135mm Spaced Dropouts
  • Crankset: SE V-Ridge 3-pc Cr-Mo Cranks,175mm, External Sealed Bearing Euro Bottom Bracket, 200mm Spindle length, 19mm Spindle Diameter, 27T Alloy SE Racing Sprocket
  • Pedals: X-Pedo Low-profile Platform w/ Removable Pins
  • Chain: KMC S1
  • Wheelset: Alloy 36H Hubs, Sealed Rear, 135mm Front Hub & 170mm Rear Hub, w/ SE Bubble Fat 65mm Rims, 14T Cassette, Stainless Spokes
  • Tires: Vee Tire Co x SE Racing Chicane, 26" x 3.5", 72TPI, Front & Rear,
  • Brakeset: Tektro Auriga, Hydraulic Disc, Easy to Adjust Open System, Dual Piston, Automatic Caliper Positioning, 180mm Front Rotor, 160mm Rear Rotor
  • Brake Levers: Tektro Auriga, 2-Finger Alloy, Front & Rear
  • Headset: FSA Orbit CE, Sealed 1-1/8" Integrated
  • Handlebar: Big Honkin' Cr-Mo Cruiser Bar, 29" x 7", 12° Backsweep, 2° Upsweep
  • Stem: Retro Alloy Top-Load w/ Engraved SE Logo on Top & Sides, 55mm Reach
  • Grips: Special Edition ODI Mushroom II Grips, Made in USA, w/ SE Donuts
  • Seat: SE Flyer Seat w/ Custom SE Bottle Opener Brace
  • Seatpost: Micro-Adjust Alloy, 27.2mm
  • Seat Clamp: SE Racing Champ Clamp, Alloy, 31.8mm Inner Diameter
  • Accessories: Alloy Valve Caps, SE Chain Tensioners
  • Weight: 35.8 lbs / 16.23 kgs
Sizing:
  • Suggested Rider Size: 5'3"+ (160cm+)
Geometry:
  • Top Tube, Actual: 22.2"
  • Seat Tube, Center To Top: 14.9"
  • Seat Tube Angle: 72°
  • Head Tube Angle: 70°
  • Chainstay Length: 17.8"
  • Wheelbase: 42.6"
  • Bottom Bracket Height: 12.4"
  • Standover: 30"
It was only a matter of time until we created the fattest Quad of them all, the Fat Quad! This fat BMX bike is centered around the unique Quadangle frame design featuring an oversized downtube, integrated head tube and a legendary looptail rear end. New this year is an upgrade to Tektro Auriga hydraulic disc brakes. Once you go fat, you never go back...

Important Note: Our bikes require some assembly on delivery. See our Warranty Page for more details.
